Wasser Pipes by Astral Industries Limited

Reliable Flow Starts with the Right Pipe.

Wasser HDPE pipe for water supply, boreholes and irrigation across Kenya. 20 mm to 110 mm, PN6 to PN20, fused into leak-free joints and supplied in lengths up to 100 metres.

Contractor or bulk order? Get a quote on WhatsApp
Black Wasser HDPE pipes with a blue stripe stacked in front of a house, a raised water tank and an irrigated field in Kenya

HDPE Pipe

63 mm · PN10

Wall
3.8 mm
Bore
55.4 mm
Rated
10 bar
Outside diameters
20–110 mm
Pressure classes
PN6–PN20
Longest supplied length
100 m
Maximum working temperature
65°C

Size finder

Two taps to your HDPE pipe

Pick the diameter and the pressure class. You get the wall thickness, the bore, the product code and a buy button.

Diameter

Nominal outside diameter, in millimetres.

Pressure class

The PN number is the working pressure in bar. Pumped and borehole lines need a higher class than gravity lines.

A starting point, not a design. Final pipe sizing and pressure class should be confirmed by a qualified plumber or engineer for your specific project.

Applications

Where it is used

One pipe for the jobs that move water across Kenya, from a household connection to a pumped main.

  • A black HDPE main with a blue stripe discharging water in a trench, with a water tank and houses behind it

    Water supply mains

    Nominal pressures PN6 to PN20, up to 20 bar at 25°C–40°C.

  • A black HDPE rising main running from a borehole up to a raised water storage tank

    Boreholes and pumped lines

    PN16 to PN20 for pumped mains and boreholes, joined by heat fusion.

  • Black HDPE irrigation mainline and laterals laid between crop rows, with sprinklers running behind

    Farms and irrigation

    Produced in 50 m to 100 m lengths, so long runs need few joints.

  • Large black HDPE pipework with a flanged valve at an industrial plant

    Gas and industry

    HDPE pipes for water and gas from 20 mm to 110 mm.

Close-up of a fused joint between two lengths of black HDPE pipe with a blue stripe
A length of black Wasser HDPE pipe with a blue identification stripe, printed "Wasser Pipes HDPE"

Wasser HDPE

HDPE Pipe

Black high-density polyethylene pipe for water and gas, joined by heat fusion into leak-free, fully restrained joints.

  1. Heat-fusion joints are as strong as, or stronger than, the pipe itself
  2. Produced in 50 m to 100 m lengths, cutting the number of joints
  3. Light, flexible and lower in construction cost than other pipe materials

PN6–PN20 · 20–110 mm · 6 m to 100 m lengths · Black

Look inside

See the wall at each pressure class

Pick a size and a PN class and turn the pipe: the wall is drawn to scale from the spec table.

  • HDPE wall by PN
  • Fused joint
OD 63 mmbore 55.4 mmwall3.8 mm

Diagram

The PN class is the wall thickness

Size (mm)
Pressure class
Wall
3.8 mm
Bore
55.4 mm
Rated
10 bar

The outside diameter stays the same; a higher pressure class has a thicker wall and a slightly smaller bore. Pick a size and a class to see the real proportions.

Plan a project with this pipe

Contractors · plumbers · projects

Bulk order? Get a quote on WhatsApp.

Tell us the size and how many metres. The message is written for you and goes straight to the Astral Industries sales team.

Opens WhatsApp with your answers already written. Add your name and delivery location, then send. We call you about the delivery fee.

FAQs

Questions we get asked before an order

All 11 questions

  • What sizes does Wasser HDPE pipe come in?

    Nine outside diameters: 20, 25, 32, 40, 50, 63, 75, 90 and 110 mm, for water and gas. Wall thickness for every size and pressure class is published on the HDPE product page.

  • What pressure classes is Wasser HDPE pipe made in?

    PN6, PN8, PN10, PN12.5, PN16 and PN20. The PN number is the recommended maximum operating pressure in bar at 25°C to 40°C. Not every size is made in every class: 20 mm is made in PN16 and PN20 only, and PN6 starts at 50 mm.

  • How do I pay for my order?

    Pay by M-Pesa, Paybill 208911, before delivery, or approve the M-Pesa prompt we send to your phone. Pay only to Astral Industries Limited. Never to a personal number.

  • How long does delivery take?

    Delivery takes 2 to 5 days, depending on the order and the route, and 5 days at most, even to remote places. The delivery place must be reachable by road. If it isn’t, we meet you at the nearest road a truck can reach. We call you about the delivery fee.

  • Can I collect my order?

    Yes. Collect your order free, any day, from Mombasa, Infinity, Isinya or Eldoret, once it is confirmed.

Request a quote

Tell us about the project

Send the details and the Astral Industries Limited team will come back with a quotation and the right specification for the work.

Prefer to review the range first?

Sizes, pressure classes and product codes for Wasser HDPE pipe are on the products page.

Loading the enquiry form…
